Sheet Metal Punching
Our high-speed CNC Punching capabilities allow us to apply stampings and features to sheet metal parts such as countersinks, louvres, upforms, ribs, embosses and hinge assemblies.
Anpllocnc’s CNC punching facilities allow us to offer unbeatable productivity, reliability and flexibility as well as ultimate efficiency through automated “lights out” production.
24-hour operation of the unmanned CNC punching machines gives greatly improved productivity with considerable quality improvements. Our customers profit from an unrivalled process consistency, offering industry-leading punching standards.
CNC Sheet Metal Punching Services
In addition to our full range of metal fabrication services, we also offer precision Sheet Metal Punching services. Our punching machines have the capability and automation to produce high-volume metal parts, and our CNC punching meets the highest industry standards.
Through our continuous improvement efforts, we have streamlined the punch manufacturing process so we can quickly deliver the precision punched parts you need. Whether you need complex assembly or high-volume production support with CNC turret stamping, we can help. Our team of customer service representatives, engineers, and quality technicians can help you get your parts into production.
Anpllocnc’s one-stop service for all your CNC metal punching needs. Our services can dramatically improve your productivity and performance while delivering cutting-edge solutions. We work with a variety of industries on a variety of metal and CNC turret punching projects, including agriculture, construction, medical, oil and gas, transportation and more.
You benefit from the unparalleled level of consistency and quality we offer. Quick turnaround including stamped part number stamping, special shapes, rib forming, tapping and countersinking to create ultra-precision holes and shapes. Additionally, we are able to eliminate costly secondary operations such as hardware insertion, machining, edge trimming and reaming.
We support rapid production planning, inventory planning, JIT delivery and custom packaging solutions. Every effort is made to get you better parts faster!
Metal Punching Parts Online Quote
Anpllocnc is proud to offer a wide range of perforated metal products in our inventory to meet our customers’ requirements. If your project requires sheet metal fabrication services like punching services, our metal punch presses apply just the right amount of pressure to the metal to create the perfect punch hole, working in metal up to 1 inch thick. Our experience helps us provide our customers with hole size recommendations that will not compromise the integrity of their products.
Our customers range from industrial, commercial and construction. This gives us an advantage as we regularly handle all types of custom punch orders. From perforated infill panels, to machine guards, to perforated baffle orders, we’re here to serve you. Get a quote now using our online instant quote system.
Precision sheet metal punching and forming capabilities
- Contract Manufacturing
- Prototypes
- Aircraft Assemblies and Components
- Building Products
- Bus Assemblies
- Doors
- Drawers
- POP Display Fixtures
- Sheet Metal Parts
- Steel Panels
- Subsystem Enclosures
- Bending – 240 Ton Breaks with 13′ Bed 8-Axis
- Folding
- Forming
- Laser Cutting
- Painting
- Plating
- Powder Coating
- Punching – CNC Turrets with auto Index 5′ X 10’Bed
- Rolling
- Shearing
- Stamping
- Water Jet Cutting
- Welding
- CNC
- Manual
- Robotic Load/Unload
- 24 Gauge up to 1/2″
- 156 in.
- .005 in.
- 156 in.
- ISO – Compliant (International Organization for Standardization)
- Quoted on job by job basis
- Emergency services available
- Rush Services Available
- Aerospace
- Agricultural
- Architectural
- Automation
- Construction
- Medical
- Ornamental
- Railroad/Locomotive
- Signage
- Build
- Consulting
- Design
- Finite Element Analysis (FEA)
- Rapid Prototyping
- AutoCAD (DWG,DWZ)
- BMP (Bit Mapped Graphics)
- DXF (Drawing Interchange Format, or Drawing Exchange Format)
- GIF (Graphics Interchange Format)
- IGES (Initial Graphics Exchange Specification, ANSI file format.)
- Pro-E or Pro/Engineer (DRW,PRT,XPR)
- SolidEdge (DFT)
- SolidWorks (SLDPRT,SLDDRW,SLDDRT)
General Dimensional Tolerances
| Dimension Range | DIM ≤ 8″ [203mm] 8″ [203mm] < DIM ≤ 16″[406mm] 16″[406mm] < DIM ≤ 36″[914mm] |
| Edge to Edge, Hole to Hole, Edge to Hole on Flat | ± 0.005″ [0.13mm] ± 0.010″ [0.25mm] ± 0.015″ [0.38mm] |
| Edge to Hole to Bend | ± 0.010″ [0.25mm] ± 0.015″ [0.38mm] ± 0.020″ [0.38mm] |
| Bend to Bend | ± 0.020″ [0.51mm] ± 0.020″ [0.51mm] ± 0.030″ [0.76mm] |
| Angular Tolerance | ±2° |
General material tolerances
| TOLERANCE CLASS | LINEAR DIMENSION TOLERANCES – NORMAL SIZE RANCE IN inch | ||||
| .020 < DIM ≤ .125 | .125 < DIM ≤ .25 | .25 < DIM ≤ 1 | 1 < DIM ≤ 5 | 5 < DIM ≤ 16 | |
| F (FINE) | ±0.002 | ±0.002 | ±0.005 | ±0.005 | ±0.008 |
| M (MEDIUM) | ±0.005 | ±0.005 | ±0.008 | ±0.125 | ±0.020 |
| TOLERANCE CLASS | RADII AND CHAMFERS | ANGLES | |||
| M (MEDIUM) | ±0.008 | ±0.020 | ±0.040 | ±1° | ±2° |
Sheet Metal Punching: Defined
Sheet metal punching in metal fabrication is the process of using a machine to press a shape through a sheet of metal and into a die to create the desired shape in the metal. This is most commonly done by use of a turret, a computer numerical controlled machine that houses tools and their corresponding dies in a revolving indexed turret. These machines use hydraulic, pneumatic, or electrical power to press the shape with enough force to shear the metal. The shape is formed by pressing the material against a die with a huge force. The shear forces generated between the material and die separate the material into the desired shape. The desired shape is not obtained, however, as burred edges and rough surfaces are formed. These edges and surfaces must be further processed until the desired shape is achieved.
The Benefits of CNC Sheet Metal Punching
- Versatility: Sheet metal punching can be used to create a wide range of shapes and sizes, from simple round holes to complex cutouts and embossing enabled by custom tooling.
- Tight tolerances: CNC punch presses offer precise control over the punching process, resulting in high accuracy and repeatability.
- High speed: Metal punching process is fast and can produce many almost-identical parts quickly and efficiently.
- Cost-effective: For high-volume production runs, punching can be the cheapest option. The higher the volume, the lower the cost per part as it drives down the impact of setup costs (and custom tooling, if needed) on the total price.
- Minimal material waste: Sheet metal punching is a highly efficient process that produces minimal material waste compared to other cutting methods. The punched sheet metal can also be recycled, reducing environmental impact.
- Customisation: Punches and dies can be custom-made to produce complex shapes and features, allowing for the customisation of parts to meet specific design requirements.
- Consistency: Punching offers high consistency and uniformity across a production run, resulting in parts that fit together precisely and work as intended.
- No HAZ: Unlike thermal cutting methods like laser or plasma cutting, punching does not heat the metal. Thus, it is free of heat-affected zones.
Our Fully Equipped Custom Fabrication Shop Is Ready to Assist You
As part of our ongoing quest to provide the best solution for every customer, we have a state-of-the-art, in-house fabrication department that contains the most advanced hole punching equipment on the market. This enables us to offer a wide assortment of premium perforated metal custom punching services, including:
- Hole size: If our standard round, slotted or square hole sizes aren’t quite right for your project, just let us know! We can alter the size of the hole to make it larger or smaller as needed.
- Hole pattern and pattern orientation: Typical perforation patterns include variations of straight-line and staggered. However, we can alter these patterns upon request. We can also change the pattern orientation and direction.
- Open area percentage: The amount of open area on a screen, vent or other product will significantly affect factors such as material flow and strength. We can custom fabricate your metal sheets or coils to contain the precise open area percentage that will provide the results you need, while also providing maximum durability.
Why Choose Anpllocnc?
Efficiency
By reducing the risk of human error and eliminating the need for additional resources, our automated machines improve the efficiency of the punching process - helping us deliver low-cost, reliable sheet metal manufacturing to all of our clients.
Inspection
Inspection of a welded product is critical in modern-day manufacturing. This is carried out by our highly qualified in-house team, who are continually updating their accreditations.
Quality
Our welding operators hold ISO 15614 and ISO 9606 qualifications. United in a common goal and reliant upon a quality response from each other, our expert team deliver a consistently exceptional service.
Other Sheet Metal Fabrication Solution
Sheet Metal Bending Services
With our extensive experience in sheet metal bending and our advanced equipment, we can handle sheet metal bending parts manufacturing tasks for any industry.
We can manufacture exactly what is needed: angles, “U” shapes, multiple bent shapes, “C” shapes, etc., as well as all complex product designs. Provides the same dimensional and fit tolerance consistency, +/- .05mm accuracy on features or edges.
Anpllocnc will always exceed your quality expectations.
Laser Cutting Services
We have advanced 10.000kw industrial-grade laser cutting equipment, which handles fine engraving and cutting details on the metal sheet metal, and can cut stainless steel plates within 30mm at the maximum. The flat cut cross section can reduce the cost of secondary processing.
And to achieve a precision tolerance of ±0.05mm, more than 80 kinds of metal plate materials can be selected.
Laser cutting service is suitable for sheet metal prototypes and mass production, and is time-efficient and economical.
At Anpllocnc, we can ship semi-finished products after laser cutting on the same day.
Welding Fabrication Services
Metal welding is an indispensable process for manufacturing parts of sheet metal. The metal is spliced and assembled at high temperature and will maintain high strength after cooling.
Metal welding is classified according to different media: gas flame, electric arc, laser, electron beam, friction and ultrasonic. It is widely used in the welding of various metal materials.
At Anpllocnc, we use advanced welding robots for fully automated welding work.
contact us
Do you want to manufacture a complex and assembled final product?
Would you like to receive the assembled Sheet Metal Punching product? Whether it is complex structure, strict standards of products, or a small number of orders.Anpllocnc can be solved smoothly, you do not need to bear any risk, protect your investment security.Quality. Speed. Reliability. That’s what you get when you choose Anpllocnc Specialty Steel for all your perforated metal needs!
